Huidu HD-WF4 (WF4 for short) comes with 4 HUB75E interfaces. It is a single and double color series colorful control card. It supports Wi-Fi and U disk two ways to update programs. It is suitable for door screens, storefront sign screens, Vendor screens, car screens and other occasions. WF4 supporting computer software HD2020 or mobile phone APP - "Screen Control", the software interface is simple, easy to operate, rich in display methods, low cost and high cost performance, and supports various full-color modules.

Huidu HD-WF4 Single and double color colorful series control card Features：

1. Built-in antenna, save installation trouble;
2. Support program frame, region frame, support custom frame;
3. Support a variety of text effects to meet most application scenarios;
4. Support font hollow, stroke and other designs;
5. Support up to 20 content areas, free typesetting;
6. Support external temperature and humidity sensors;

Huidu HD-WF4 Single and double color colorful series control card function list：

Mod type				Support full-color module of HUB75 interface, support conventional and 2038S chips
scanning method				Support static to 1/32 scan
Control range				768*64, the highest 128, the widest 1280
way of communication				way of communication
storage				8M Byte
Support colorful				Red, green, blue, yellow, purple, cyan, white can be displayed without gray scale
Support colorful				Up to 8 levels of grayscale, support colorful text
number of programs				999, support Wi-Fi remote switching
number of regions				20, independent partitions, independent special effects, independent borders, overlapping areas
Display content				Text, animated words, 3D text, pictures, GIF animation, time, timing, lunar calendar, etc.
switch machine				Support timer switch settings
extension device				Temperature, remote control, photosensitive, etc.
Dimming				Support brightness setting, brightness setting by time interval
Power supply				Standard terminal post power supply
Working power
Product Weight
Certification				CE, FCC, RoHS

Specification Download:

Huidu HD-WF4 Single and double color colorful series control card Specification
